To create a VNC-based application, you need admin privileges to configure your environment, including adding applications. Please refer to the following knowledge base articles about Admin access: Login to Admin Portal
Steps to create a VNC-based application:
- Go to the Settings tab > ZTNA.
- In Application, choose Applications.
- Click New Application, then fill in the fields as follows:
- Name: Enter a unique name for the application (this is a required field).
- Application Address/FQDN/Hostname: Provide the address of your internal business app using IP format (e.g., 192.168.1.100), FQDN (e.g., app1.coba.lan), or hostname (e.g., app1).
- Site: This is optional. You can leave it as "all" for a single-site deployment, but for a multisite deployment, it's recommended to choose the correct site based on the application location.
- Access URL: This will be automatically created based on the application name, but you can customize the subdomain if desired.
- Toggle Visible: By default, this is enabled. If disabled, the app will not appear in the user portal.
- Icon: This will automatically populate for standard HTTP/S applications, but you can customize it by uploading a different icon.
- Category: This is optional. It helps to organize applications by type. By default, it will use the "uncategorized" tag. For more information, please find here.
- Protocols: Ensure that this is set to "VNC".
- Port: By default, this will use the standard VNC port (5900), but you can change it if needed.
- Single Sign-On (SSO): This is optional. If your app supports SSO, you can enable it. More information about SSO can be found here.
- SSO Options: Choose one of the SSO options available for the application. You can either use the user's filled credentials, the user's personal vault, or assign a credential stored in the Vault.
- Vault Credential: If you choose to use the Vault, select the credential stored in the Vault.
Once all the fields have been filled out, click Save.
